Fiber Laser Marking is a printing technology that uses fiber laser beams to create marks or engravings on various materials such as metals and plastics. Gressler’s Fiber Laser Marking system offers sharp accuracy for intricate details, fine fonts, and complex patterns, making it ideal for industries that demand high precision.
The Gressler GL2000 can process a wide range of materials, including metals, plastics, and ceramics, making it suitable for diverse industrial applications.
With high-speed performance and fast repetition rates, the GL2000 Fiber Laser Marking system enhances production efficiency in high-speed manufacturing environments. Its solid-state design requires minimal maintenance and provides a long operational lifespan, helping to reduce operational costs.
Speed Max: 8m / second (Linear)
Laser Beam: Deflection Digital High-Speed Galvanometer Scan
Marking Size: 110 x 110 mm
User Interface and System: 10'4 Inch with Android System
| Specifications | GL2000 |
|---|---|
|
Laser Type |
Pulsed Fiber Laser |
|
Laser Power |
30W, 50W, 60W |
|
Wavelength |
1064nm |
|
Laser Frequency
|
20K HZ – 80KHZ
|
|
Focal Distance |
170mm |
|
Speed |
Max 8m / second (Linear)* |
|
Laser Beam
|
Deflection Digital High-Speed Galvanometer Scan |
|
Marking Size |
110 x 110mm |
|
User Interface and System |
10’4 Inch with Android System |
| Coding Features | |
|---|---|
|
Machine Readable Codes |
Alphanumeric, Text, Counter, Box/Lot, Date/ Time, Best Before Date, Julian Date, Shift code, Graphic, Database. 1D & 2D Codes, Code 11, Code 39, Code 128, EAN, QR, DataMatrix, GS 1 DataMatrix) |
|
Design Software Compatibility |
CorelDRAW, AutoCAD, and Photoshop, and comprehensive compatibility with a range of file formats including AI, PLT, PCX, DXF, and BMP. |
|
Supported Font and Language |
Standard Windows® TrueType® (TTF), PostScript® (PFA, PFB), OpenType® (OTF) Custom fonts tailored for high-speed or OCR applications and multiple selection of languages. |
| Operations & Integration | |
|---|---|
|
Operating Temperature / Humidity |
10-40 °C / 10%-90% RH, No Condensation |
|
Electrical Power Supply |
220V/50H/5A/1P |
|
Power Consumption |
Less than 500W |
|
Cooling System |
Air Cooling |
| Optional Accessories | |
|---|---|
|
Laser head bracket mount, user interface mount, sensor and sensor mount, print head cover, fume extraction |
|
The Gressler Fiber Laser Marking system enables the highest level of precision and detail in marking applications. Designed to deliver sharp accuracy, this fiber laser effortlessly creates intricate details, fine fonts, and complex patterns, making it the ideal choice for industries where precision is a must.
The Gressler GL2000 Fiber Laser Marking system’s ability to process a wide range of materials—including metals, plastics, ceramics, and more—makes it highly adaptable for various marking tasks. Its flexibility opens up numerous possibilities, making it suitable for diverse industrial applications.
The Gressler GL2000 Fiber Laser Marking system offers exceptional speed, with high marking speeds and rapid repetition rates, enabling quick and efficient marking processes. This capability significantly boosts production efficiency and throughput in high-speed manufacturing environments.
The compact, solid-state design of the Gressler Fiber Laser minimizes maintenance needs, reducing operational costs and production downtime. Combined with the long lifespan of its optical fiber components, this system provides enhanced cost-effectiveness over time, making it a smart investment for industries seeking reliability and efficiency.
The compact design of the Gressler Fiber Laser Marking system allows for easy integration into any production line, saving valuable workspace while maintaining high performance. Its efficient operation not only reduces energy consumption but also supports cost savings and environmental sustainability.
